304 304L 316 316L Daqsijiet U Piż tat-Tubi Stainless Steel
Oct 20, 2023
304 304L 316 316L Daqsijiet u Piż tat-Tubi tal-Azzar Stainless
OD f'mm, Piż f'kgs/m (Bażi tar-riżultat tal-piż fuq Ikkalkula ta' "Piż= 0.02507 ×T (D – T )".)
| Ħxuna tal-ħajt mm OD mm |
0.5 | 0.6 | 0.7 | 0.8 | 1.0 | 1.2 | 1.6 | 2.0 | 2.6 | 3.0 | 3.2 | 3.6 |
| 6.0 | 0.069 | 0.081 | 0.093 | 0.104 | 0.125 | 0.144 | 0.176 | – | – | – | – | – |
| 10.0 | 0.119 | 0.141 | 0.163 | 0.184 | 0.225 | 0.264 | 0.336 | – | – | – | – | – |
| 12.7 | 0.153 | 0.182 | 0.210 | 0.238 | 0.293 | 0.345 | 0.444 | – | – | – | – | – |
| 14.0 | 0.169 | 0.201 | 0.233 | 0.264 | 0.325 | 0.384 | 0.496 | – | – | – | – | – |
| 15.87 | 0.192 | 0.229 | 0.266 | 0.301 | 0.372 | 0.440 | 0.571 | 0.694 | – | – | – | – |
| 19.0 | 0.231 | 0.276 | 0.320 | 0.364 | 0.450 | 0.534 | 0.696 | 0.850 | 1.066 | 1.200 | 1.264 | – |
| 25.0 | 0.306 | 0.366 | 0.425 | 0.484 | 0.600 | 0.714 | 0.936 | 1.150 | 1.456 | 1.650 | 1.744 | 1.926 |
| 25.4 | 0.311 | 0.372 | 0.432 | 0.492 | 0.610 | 0.726 | 0.952 | 1.170 | 1.482 | 1.680 | 1.776 | 1.962 |
| 31.75 | – | – | – | – | – | 0.918 | 1.208 | 1.490 | 1.898 | 2.160 | 2.288 | 2.538 |
| 38.0 | – | – | – | – | – | 1.104 | 1.456 | 1.800 | 2.301 | 2.625 | 2.784 | 3.096 |
| 44.5 | – | – | – | – | – | 1.299 | 1.716 | 2.125 | 2.724 | 3.113 | 3.304 | 3.681 |
| 50.8 | – | – | – | – | – | – | 1.968 | 2.440 | 3.133 | 3.585 | 3.808 | 4.248 |
| 63.5 | – | – | – | – | – | – | 2.476 | 3.075 | 3.959 | 4.538 | 4.824 | 5.391 |
| 76.1 | – | – | – | – | – | – | 2.980 | 3.705 | 4.778 | 5.483 | 5.832 | 6.525 |
| 101.6 | – | – | – | – | – | – | 4.000 | 4.980 | 6.435 | 7.395 | 7.872 | 8.820 |
| 114.3 | – | – | – | – | – | – | 4.453 | 5.547 | 7.173 | 8.247 | 8.780 | 9.840 |
| 127 | – | – | – | – | – | – | 4.955 | 6.175 | 7.989 | 9.188 | 9.785 | 10.980 |
| 152.4 | – | – | – | – | – | – | 5.960 | 7.429 | 9.620 | 11.070 | 11.792 | 13.231 |
304 tainless Steel Tube
304 304L 316 316L Ċart tad-Daqsijiet tat-Tubi tal-Azzar Stainless
| BWG | BWG | BWG | BWG | BWG | BWG | BWG | BWG | ||
| 25 | 22 | 20 | 18 | 16 | 14 | 12 | 10 | ||
| WT mm | WT mm | WT mm | WT mm |
WT mm | WT mm | WT mm | WT mm |
||
| Dijametru ta' Barra | Dijametru ta' Barra | 0.508 | 0.711 | 0.889 | 1.245 | 1.651 | 2.108 | 2.769 | 3.404 |
| mm | pulzier | kgs/m | kgs/m | kgs/m | kgs/m | kgs/m | kgs/m | kgs/m | |
| 6.35 | 1/4 | 0.081 | 0.109 | 0.133 | 0.174 | 0.212 | |||
| 9.53 | 3/8 | 0.126 | 0.157 | 0.193 | 0.257 | 0.356 | 0.429 | ||
| 12.7 | 1/2 | 0.214 | 0.263 | 0.356 | 0.457 | 0.612 | 0.754 | ||
| 15.88 | 5/8 | 0.271 | 0.334 | 0.455 | 0.588 | 0.796 | 0.995 | ||
| 19.05 | 3/4 | 0.327 | 0.405 | 0.553 | 0.729 | 0.895 | 1.236 | ||
| 25.4 | 1 | 0.44 | 0.546 | 0.75 | 0.981 | 1.234 | 1.574 | 2.05 | |
| 31.75 | 1 1/4 | 0.554 | 0.688 | 0.947 | 1.244 | 1.574 | 2.014 | 2.641 | |
| 38.1 | 1 1/2 | 0.667 | 0.832 | 1.144 | 1.514 | 1.904 | 2.454 | 3.233 | |
| 44.5 | 1 3/4 | 1.342 | 1.774 | 2.244 | 2.894 | 3.5 | |||
| 50.8 | 2 | 1.549 | 2.034 | 2.574 | 3.334 | 4.03 | |||
| 63.5 | 2 1/2 | 1.949 | 2.554 | 3.244 | 4.214 | 5.13 | |||
| 76.2 | 3 | 2.345 | 3.084 | 3.914 | 5.094 | 6.19 | |||
| 88.9 | 3 1/2 | 2.729 | 3.609 | 4.584 | 5.974 | 7.27 | |||
| 101.6 | 4 | 4.134 | 5.254 | 6.854 | 8.35 | ||||
| 114.3 | 4 1/2 | 4.654 | 5.924 | 7.734 | 9.43 |
304L Stainless Steel Tube
